Characteristics

  • RJ45 Connector with integrated transformer / common mode choke
  • Power over Ethernet up to 50 Watt and speeds up to 10 Gbit/s
  • Available in SMT, THT and THT with USB
  • Compliant with standards: IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at and upcoming IEE 802.3bt
  • HPLE products: Improved Common Mode Rejection due to additional NiZn cores
S
Specification
Item Value
Model NumberIntegrated Connector Modules
Part StatusActive
Connector TypeRJ45
Applications-LanEthernet(PoE/Non_PoE)
Speed10/100/1000/2.5G/5G/10G Base-T, AutoMDIX
Mounting TypeThrough Hole
Orientation90° Angle (Right)
TerminationSolder
Contact Finish Thickness6.00µin (0.152µm)
LED ColorYellow/Green, Green/Yellow, Green&Yellow/Green&Yellow
Number of Cores per Jack4/6/8/12
ShieldingShielded, Emi Finger
Number of Ports1x2 1x4 1x6 1x8 Port
FeaturesBoard Guide
Tab DirectionDown/Up
Contact FinishGold
Configuration RX/TXT,C
Turns Ratio RX/TX1CT:1CT
Operating Temperature0°C ~ 70°C/-40°C ~ +85°C
P
Packing & Delivery
Package Details:
Tray Packaging | Carton size: 37*30*30cm | G.W./carton: 9kg | Qty/carton: 600pcs | SPQ: 30pcs | N.W/pcs: 0.015kg
Packing Image
V
Visual Showcase
?
Frequently Asked Questions
1. What types of Ethernet speeds do these connectors support?
Our integrated RJ45 connectors support a wide range of speeds including 10/100/1000 Base-T, as well as high-speed 2.5G, 5G, and 10G Ethernet requirements.
2. Are these connectors compatible with Power over Ethernet (PoE)?
Yes, they are compliant with IEEE 802.3af, 802.3at, and 802.3bt standards, supporting power delivery up to 50 Watts.
3. What mounting options are available for the RJ45 series?
We offer multiple mounting configurations including Through Hole (THT) and Surface Mount Technology (SMT), with both 90-degree and vertical orientations.
4. How is product quality guaranteed during production?
We perform rigorous pre-production sample testing and a final 100% inspection before shipment to ensure all electrical and mechanical specifications are met.
5. Can these connectors operate in extreme environments?
Yes, we provide options for standard operating temperatures (0°C to 70°C) as well as industrial-grade ranges (-40°C to +85°C).
6. What certifications do your products carry?
Our products are manufactured under strict quality control and are compliant with international standards including UL, REACH, CE, and ISO9001:2008.
