WaveLink
WaveLink
| Item | Value |
|---|---|
| Model Number | LPJG46801AENL |
| Part Status | Active |
| Connector Type | RJ45 |
| Applications | 10/100/1000 Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Contact Finish Thickness | 6.00µin (0.152µm) |
| LED Color | Green - Yellow |
| Number of Cores per Jack | 8 |
| Shielding | Shielded, EMI Finger |
| Number of Ports | 1X4 Port |
| Features | Board Guide |
| Tab Direction | Down |
| Contact Finish | Gold |
| Configuration RX/TX | T,C |
| Turns Ratio RX/TX | 1CT:1CT |
| Operating Temperature | 0°C ~ 70°C |
100 / 1000 / 2.5G / 5G / 10G Base-T 1xN RJ45 Connector
Suitable for industrial temperatures from –40 °C up to +85 °C. Compatible with Industrial Ethernet systems like EtherCAT or Profinet. Compliant with most IC’s for Ethernet applications such as Microchip, Broadcom, Marvell, Hubs, Routers, Switches, IP cameras, and IoT applications.
Package Details: 20 pcs in 1 tray, 20 trays in 1 carton.
Dimensions: 37 x 30 x 30 cm
Weight: 10 KGS (400 pcs) per carton.
