Technical Specifications
| Part Number | LPJG47036AWNL |
| Application-LAN | ETHERNET(POE) |
| Auto MDIX | YES |
| Bst Circuit | YES |
| Configuration RX/TX | T,C / T,C |
| Contact Mating Area Plating | GOLD 6u"/15u"/30u"/50u" |
| Cores Per Port | 8 |
| Diodes | NO DIODES |
| LED Option | GREEN/GREEN |
| Latch | UP/DOWN |
| Number of Ports | 2X4 |
| PCB Material | FR4 |
| PCB Mount Angle | SIDE ENTRY |
| PCB Retaining Post | T POST |
| Pin Type | THT SOLDER |
| RoHS Compliant | YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION |
| Shield EMI Tabs | WITH |
| Shielding | Shielded |
| Speed | 2.5G BASE-T |
| Temperature | -20°C to +70°C |
| Turns Ratio RX/TX | 1CT:1 / 1CT:1 |
Product Features
Preferred Supplier for leading global technology brands.
High-speed 2.5G Base-T performance for modern networking requirements.
Integrated logo visibility on high-end BeagleBone boards.
Why Choose This Solution
Professional Certification
ISO 9001:2008 Certified
UL Certification & Reach Certification
RoHS Compliance & Active Environmental Policy
100% Quality Guarantee
Manufactured Under Strict Controls
100% Tested (Not Just Batch Tested)
Quality Guarantee: 6 Years
Competitive Edge
More Competitive Price Structure
Standard Lead Time: 2-3 Weeks
Custom Design Provision for Specific Requirements
Frequently Asked Questions (FAQ)
What is the data transfer speed of this RJ45 connector?
This connector supports high-speed 2.5G Base-T Ethernet performance, making it suitable for modern high-bandwidth networking applications.
Does this 2x4 Port connector support PoE?
Yes, this component is specifically designed for ETHERNET (PoE) applications, allowing for power delivery over Cat5e cabling.
What is the operating temperature range for this product?
The connector is designed to operate reliably within a temperature range of -20°C to +70°C.
What certifications does the product hold?
The product is manufactured under ISO 9001:2008 standards and holds UL, Reach, and RoHS certifications.
Is the quality of each batch guaranteed?
Yes, we provide a 100% testing guarantee. Unlike standard batch testing, every single unit is tested to ensure functionality and reliability, backed by a 6-year quality guarantee.
What is the mounting configuration for this connector?
It features a 2x4 port configuration with a Side Entry PCB mount angle and uses THT (Through-Hole Technology) soldering for secure attachment.
