| Form Factor | SFP |
| Max Data Rate | 4.25Gbps |
| Wavelength | 1310nm |
| Max Cable Distance | 40km |
| Connector | Duplex LC |
| Media | SMF |
| Transmitter Type | DFB |
| Receiver Type | PIN |
| EMC Supported | Yes |
| DDM/DOM | Supported |
| Protocols | MSA Compliant |
| Temperature Range | 0 to 70°C / -40 to 85°C |
| Warranty | 5 Years |
| Sample | Available |
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module. We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
| Data Rate | Wavelength | Distance | Media | DDM |
|---|---|---|---|---|
| 4.25Gbps | 850nm | 150m | Multi-mode | Yes |
| 4.25Gbps | 850nm | 300m | Multi-mode | Yes |
| 4.25Gbps | 850nm | 500m | Multi-mode | Yes |
| 4.25Gbps | 1310nm | 2km | Single Mode | Yes |
| 4.25Gbps | 1310nm | 4km | Single Mode | Yes |
| 4.25Gbps | 1310nm | 10km | Single Mode | Yes |
| 4.25Gbps | 1310nm | 40km | Single Mode | Yes |
| 4.25Gbps | 1550nm | 40km | Single Mode | Yes |
End-to-end DWDM device solutions with active modules and passive devices, including optical amplifiers (EDFA & RFA), Mux & Demux, OPM, ROADM, MCS, OLP, and OTDR.
High-speed optical interconnect solutions for data centers with product rates ranging from 10G to 800G, ensuring high-quality mass data transmission.
High reliability products featuring mature lasers and mainstream chip solutions for 4G/5G systems, covering Dark Fiber, WDM, and Radio over Fiber.
Total fiber access solutions and O&M systems integrating optical line protection (OLP) and monitoring (OLM) for communication stability.
We are a specialized manufacturer of magnetic telecom and network components, certified by ISO9001, RoHS, REACH, CE and UL. Our production facilities utilize advanced manufacturing and testing equipment. With abundant production capacity, we deliver high-quality optical modules for fixed access, wireless, carrier Ethernet, and cloud computing networks worldwide.
