| Item | 2.5G SFP |
| Part Status | Active |
| Form Factor | SFP |
| Max Data Rate | 2.5Gbps |
| Wavelength | 1310nm |
| Max Cable Distance | 2km |
| Media | SMF |
| Connector | Duplex LC |
| Optical Component | FP/PIN |
| TX Power | -10~-3dBm |
| Receiver Sensitivity | <-18dBm |
| Receiver Overload | -3dBm |
| Power Consumption | 1W |
| Extinction Ratio | >8.2dB |
| DDM/DOM | Supported |
| Commercial Temperature Range | -10 to 70°C (-37 to 158°F) |
| Protocols | SFP MSA(INF-8074i), GR-253-CORE, ITU-T G.957, FC-PI v2.0, SFF-8472 v9.5 |
| Warranty | 5 Years |
| Sample | Available |
Our facility is a specialized manufacturer of magnetic telecom and networking components, certified by ISO9001:2000, ROSH, REACH, CE, and UL. We own advanced manufacturing facilities and test equipment imported from abroad. Established in 1997, we have a significant professional workforce. With an abundant monthly production capacity, we ensure efficient delivery within short lead times.
We provide professional complete solutions for magnetic components and strong technical support. Main product categories include 10/100/1000M LAN pulse transformers, RJ45 connectors with integrated magnetics, T1/E1/T3/DS3 interface transformers, and SFP modules. Our products are widely used in networking equipment such as hubs, switches, routers, IP phones, and xDSL modems, exported to more than 30 countries globally.
