| Item | Fiber Optical Modules |
| Vendor Name | Professional OEM/ODM |
| Part Status | Active |
| Form Factor | QSFP |
| Max Data Rate | 103.125Gbps (4x 25.78Gbps) |
| Max Cable Distance | 70m@OM3 / 100m@OM4 |
| Wavelength | 850nm |
| Connector | MTP/MPO-12 |
| Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
| Transmitter Type | VCSEL 850nm |
| TX Power | -8.4~2.4dBm |
| Receiver Sensitivity | <-10.3dBm |
| Power Budget | 1.9dB |
| Receiver Overload | 2.4dBm |
| Power Consumption | ≤2.5W |
| Extinction Ratio | >3dB |
| DDM/DOM | Supported |
| Warranty | 5 Years |
| Sample | Available |
| Protocols | IEEE 802.3bm, QSFP28 MSA, SFF-8665, SFF-8636, RoHS, CPRI, eCPRI |
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module. We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
We are a specialized manufacturer of magnetic telecom and networking components, certified by ISO9001:2000, RoHS, REACH, CE, and UL. Our facility owns advanced manufacturing facilities and test equipment imported from abroad.
Established in 1997, we currently have a large dedicated team. With an abundant monthly production capacity, we are able to deliver products within a short lead time.
Furthermore, we provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks. The range also offers high-speed optical interconnection solutions for cloud computing and ultra-broadband networks.
