WaveLink
WaveLink
| Key Specifications | |
|---|---|
| Vendor Name | Original OEM Manufacturer |
| Part No. | LS-BL553101-15C |
| Form Factor | SFP |
| Max Data Rate | 155Mbps |
| Wavelength | 1550nm-TX/1310nm-RX |
| Max Cable Distance | 15km |
| Connector | Simplex LC |
| Media | SMF |
| Transmitter Type | FP |
| Receiver Type | PIN |
| TX Power | -15 ~ -8dBm |
| Receiver Sensitivity | < -30dBm |
| EMC (Electro Magnetic Compatibility) | Supported |
| DDM/DOM | Supported |
| Protocols | Fast Ethernet, Gigabit Fibre Channel, MSA Compliant |
| Temperature Range | 0 to 70°C / -40 to 85°C |
| Warranty | 5 Years |
| Sample | Available |
We draw on over 10 years of experience in chips and modules to integrate fast speeds, small size, power savings, and high performance in every module.
We provide a full series of optical modules for fixed access, wireless access, carrier Ethernet, wavelength division multiplexing (WDM), and data communication networks.
| Part Number | Data Rate | Wavelength | Distance | Components | DDM |
|---|---|---|---|---|---|
| LS-BL315501-10C | 155Mbps | 1310nm-TX/1550nm-RX | 10km | FP/PIN | Yes |
| LS-BL553101-10C | 155Mbps | 1550nm-TX/1310nm-RX | 10km | FP/PIN | Yes |
| LS-BL315501-15C | 155Mbps | 1310nm-TX/1550nm-RX | 15km | FP/PIN | Yes |
| LS-BL553101-15C | 155Mbps | 1550nm-TX/1310nm-RX | 15km | FP/PIN | Yes |
| LS-BL315501-20C | 155Mbps | 1310nm-TX/1550nm-RX | 20km | FP/PIN | Yes |
| LS-BL553101-20C | 155Mbps | 1550nm-TX/1310nm-RX | 20km | FP/PIN | Yes |
| LS-BL315501-40C | 155Mbps | 1310nm-TX/1550nm-RX | 40km | FP/PIN | Yes |
| LS-BL553101-40C | 155Mbps | 1550nm-TX/1310nm-RX | 40km | FP/PIN | Yes |
| LS-BL315501-80C | 155Mbps | 1310nm-TX/1550nm-RX | 80km | FP/PIN | Yes |
| LS-BL553101-80C | 155Mbps | 1550nm-TX/1310nm-RX | 80km | FP/PIN | Yes |
| LS-BL495501-80C | 155Mbps | 1490nm-TX/1550nm-RX | 80km | DFB/PIN | Yes |
| LS-BL554901-80C | 155Mbps | 1550nm-TX/1490nm-RX | 80km | DFB/PIN | Yes |
We provide end-to-end DWDM devices along with almost all optical devices - from active modules to optical passive components, including optical amplifiers (EDFA & RFA), Mux & Demux, OPM, ROADM, MCS, OLP, and OTDR solutions.
To meet the rising demand for massive data transmission in enterprise data centers, we have developed a broad series of high-speed optical modules with data rates spanning from 10G to 800G, delivering top-quality optical interconnection solutions.
We deliver high-reliability and high-performance products built on mature, efficient lasers and mainstream chipsets. Solutions include Dark Fiber, WDM, Radio over Fiber, High Speed, Mid-haul, and Back-haul links to fit all standard 4G/5G deployment scenarios.
Aimed at global telecommunication system developers, we support comprehensive FTTx optical fiber access solutions. Our lines cover both all-optical networks and combined optical-copper access frameworks.
To safeguard standard optical network operations, we supply optical fiber cable operation and maintenance structures integrating optical line protection (OLP) systems and optical line monitoring (OLM) systems.
We are a specialized manufacturer of magnetic telecom and network components, certified by ISO9001:2000, RoHS, REACH, CE, and UL. Our production lines feature advanced manufacturing and test equipment imported from abroad.
Established in 1997, our facility currently employs around 2,000 workers. With an abundant manufacturing capacity of 3,000K units per month, we can fulfill and deliver orders in short timespans.
Additionally, we offer complete selections of active transceivers and optical modules for fixed broadband, wireless systems, network switches, and wavelength multiplexers. By using modern optoelectronic processes, we successfully develop and deliver high-performance optical solutions globally.
We are a specialized, certified manufacturer of magnetic telecom and networking components, including RJ45 connectors, LAN transformers, RJ11 connectors, and optical SFP transceiver modules.
Yes, we can provide samples for quality inspection and verification. Shipping and transit costs are paid by the recipient.
Products that are currently in stock are ready for immediate dispatch. For mass production or large OEM orders, the typical production lead time ranges from 15 to 30 days.
Our optical transceivers come with up to a 5-year warranty. We also offer professional online technical and compatibility support from our engineering department.
Yes, we provide full OEM and ODM services. You can send us your required parameters, wavelengths, distance requirements, and compatibility brands for a detailed quote.
We have over 19 years of dedicated production experience in network components, utilizing advanced foreign automated equipment and partnering with leading global enterprises for long-term supply agreements.
