WaveLink
WaveLink
| Form Factor | SFP |
|---|---|
| Max Data Rate | 155Mbps |
| Wavelength | 1550nm-TX/1310nm-RX |
| Max Cable Distance | 80km |
| Connector | Simplex LC |
| Media | SMF |
| Transmitter Type | FP |
| Receiver Type | PIN |
| TX Power | -5 ~ 2dBm |
| Receiver Sensitivity | < -32dBm |
| DDM/DOM | Supported |
| Temperature Range | 0 to 70°C / -40 to 85°C |
| Warranty | 5 Years |
Drawing on extensive experience in chips and modules, we integrate fast speeds, compact size, power efficiency, and high performance into every optical module.
| Part Number | Data Rate | Wavelength | Distance | Components | DDM |
|---|---|---|---|---|---|
| LS-BL315501-10C | 155Mbps | 1310nm-TX/1550nm-RX | 10km | FP/PIN | Yes |
| LS-BL553101-10C | 155Mbps | 1550nm-TX/1310nm-RX | 10km | FP/PIN | Yes |
| LS-BL315501-20C | 155Mbps | 1310nm-TX/1550nm-RX | 20km | FP/PIN | Yes |
| LS-BL553101-40C | 155Mbps | 1550nm-TX/1310nm-RX | 40km | FP/PIN | Yes |
| LS-BL315501-80C | 155Mbps | 1310nm-TX/1550nm-RX | 80km | FP/PIN | Yes |
| LS-BL553101-80C | 155Mbps | 1550nm-TX/1310nm-RX | 80km | FP/PIN | Yes |
Providing end-to-end DWDM devices including active modules and optical passive devices like amplifiers (EDFA & RFA), Mux/Demux, and ROADM.
High-speed optical interconnection solutions ranging from 10G to 800G, designed to meet mass data transmission demands in modern data centers.
Support for 4G/5G infrastructure with mature laser solutions including Dark Fiber, WDM, and high-speed mid-haul/back-haul connectivity.
Our manufacturing processes are certified by ISO9001, RoHS, REACH, CE, and UL. We utilize advanced manufacturing and testing equipment to ensure every module meets strict industry standards.
