WaveLink
WaveLink
Integrating fast speeds, small size, and high performance for modern data communication networks.
| Item | LWDM SFP |
| Part Status | Active |
| Form Factor | SFP28 |
| Max Data Rate | 25.78Gbps |
| Max Cable Distance | 40km |
| Wavelength | 1286.66nm-1309.14nm |
| Connector | Duplex LC |
| Media | SMF |
| Optical Component | EML LWDM/APD |
| TX Power | -2~6dBm |
| Receiver Sensitivity | <-19dBm |
| Power Consumption | 1.5W |
| Extinction Ratio | 4dB |
| Power Budget | 17dB |
| DDM/DOM | DDM Supported |
| Temperature Range | 0 to 70°C (32 to 158°F) |
| Protocols | SFF-8431, SFF-8472 and IEEE 802.3CC Compliant |
| Warranty | 5 Years |
Drawing on over 10 years of experience in chips and modules to integrate power savings and high performance in every module. Providing a full series of optical modules for fixed access, wireless access, carrier Ethernet, and wavelength division multiplexing (WDM) networks.
Specialized manufacturer of magnetic telecom and networking components, certificated by ISO9001:2000, ROSH, REACH, CE and UL. Equipped with advanced manufacturing facilities and imported test equipment. With a productive capacity of 3000K per month, we ensure delivery within short timeframes. We offer a full range of high-speed optical interconnection solutions for cloud computing and ultra-broadband networks globally.
